The Hugong HDCUT50HF is a compact yet powerful plasma cutter with digital control and modern IGBT inverter technology. The machine features an HDVision display, Pilot ARC ignition, and PFC technology for stable performance with reduced peak power demand. Thanks to its high-frequency (HF) ignition, the HDCUT50HF cuts effortlessly through rusted, painted, or coated materials - up to 20 mm thick - without touching the workpiece.
The cutting current is steplessly adjustable via a clear and user-friendly control panel. Settings can be fine-tuned even during operation to ensure optimal results. With its lightweight, compact design, the machine is well-suited for both workshop use and mobile applications.
Suitable for cutting low-alloy steel, stainless steel, and aluminum alloys.
- PFC Module (Power Factor Correction)
Ensures lower peak load and stable performance even with fluctuating mains voltages.
- HDVision Control Panel
Segmented LED display with intuitive controls, clear and easy to use.
- Pilot ARC Ignition with HF
Reliable non-contact ignition, effortlessly cuts through rust, paint, and coatings.
- Shock-Resistant ABS Housing
The ABS housing provides protection against impacts, dust, and light moisture.
- 5-year warranty upon registration
Long-term security thanks to extended factory warranty after online registration.
Supplied with:
- Plasma cutting torch PL80M5 – 5 meters
- Ground clamp with 3-meter cable (10 mm²)
- Pressure regulator
- Ø8mm gas hose – 3 meters
Specifications
| Frequency | 50/60 Hz |
| Voltage | 230V - 1 Phase |
| Input power | 8.05kVA |
| No load voltage | 320V |
| Rated input current | 24A |
| Welding current range | 20 - 50A |
| Duty cycle @20C | 40% - 50A |
| Duty cycle @40C | 20% - 50A |
| Recommended cutting thickness | 12mm |
| Max. cutting thickness | 20mm |
| Product Dimensions: | |
|---|---|
| Product Length | 527 mm |
| Product Width | 223 mm |
| Product Height | 356 mm |
| Product Weight | 10.0 Kg |
| Package Dimensions: | |
| Package Length | 525 mm |
| Package Width | 420 mm |
| Package Height | 305 mm |
| Package Weight | 16.15 Kg |
