Pallet truck / high lifter

Pallet truck / high lifter

This Mammuth fully electric stacker offers all the benefits of a standard stacker and extends it with the convenience of electric drive. This type of stacker drives and pumps electrically, whereby 2 driving speeds are possible. The electric drive ensures that moving heavy pallets up to 1000kg is effortless. The stacker is equipped with a 24V gel battery, which is charged using the built-in 230V charger.
For extra safety, the stacker is equipped with an automatic driving speed protection. This protection ensures that the driving speed is reduced to 2km/h when the forks are higher than 500mm.
The stacker is equipped with a standard mast, these are two mast parts, one of which extends when lifted.
Easy to operate with the multifunctional ergonomic handle. This handle is equipped with smart control, a display that provides the user with all necessary information. In addition, the handle is equipped with control buttons for driving, lifting and a horn.

Specifications:

• capacity = 1000kg

• fork length x width x height = 1150 x 160 x 90mm

• lifting range = 90 - 3000mm

• total width = 830mm

• driving speed loaded = 3.5km/h

• driving speed unloaded = 4km/h

• lifting speed loaded = 100mm/s

• lifting speed unloaded = 112mm/s

• lowering speed loaded = 92mm/s

• lowering speed unloaded = 85mm/s

• max. gradeability loaded = 5%

• max. gradeability unloaded = 7%

• turning radius = 1390mm

• minimum clearance height = 2,04m

• battery = 24V - 75Ah gel battery

• operating time = 3 - 4 hours

• charging time = 8 hours

• single front wheel

• material wheels = PU

• diameter steering wheel = 210mm

• diameter load wheel = 80mm

• diameter balancing wheel = 180mm
