The Woodcraft log splitter 35 ton petrol vertical is a hydraulic log splitter for splitting roundwood and firewood. With the petrol engine, on-site use is possible, also where no mains power is available. Equipped with a tow hitch coupling, the log splitter can be taken to the workplace, for example on a yard or at wood storage.
With 35 tons of splitting force, this log splitter is suitable for logs with a diameter of 150 to 510 mm and lengths of 400 to 620 mm. In the vertical position, splitting is done upright, allowing heavy logs to be loaded from a low working height and split in line with the splitting direction.
Support legs help position the log splitter at the workplace and support the machine during splitting. Equipped with an emergency stop for immediate shutdown in an unsafe situation. Complies with NEN-EN 609-1:2017, the safety standard for wedge splitting machines with requirements for guarding and operation.
Key features:
- Splitting force 35 ton
For splitting logs with a diameter of 150 to 510 mm and a length of 400 to 620 mm.
- Petrol drive
For outdoor or on-site use where no electrical connection is available.
- Movable via tow hitch
Can be taken to the workplace, maximum towing speed 72 km/h.
- Support legs for stability
Support positioning and ensure stable setup during use.
- Complies with NEN-EN 609-1:2017, with emergency stop
Safety standard for wedge splitting machines (requirements for guarding and operation).
Specifications
| Splitting force | 35 ton |
| Maximum log diameter | 510 nn |
| Minimum log diameter | 150 mm |
| Maximum log length | 620 mm |
| Minimum log length | 400 mm |
| Working cycle time | 13.5 sec |
| Return stroke speed | 7 sec |
| Working pressure max. | 215 Bar |
| Motor capacity | 10.1 pk |
| Fuel type | Gasoline |
| Oil capacity | 25 L |
| Oil-filled | No |
| Oil type | CH32 |
| Wheel diameter | 406 mm |
| Maximum towing speed | 72 km/u |
| Product Dimensions: | |
|---|---|
| Product Length | 2,300 mm |
| Product Width | 1,400 mm |
| Product Height | 1,720 mm |
| Product Weight | 335.0 Kg |
| Package Dimensions: | |
| Package Length | 2,090 mm |
| Package Width | 590 mm |
| Package Height | 820 mm |
| Package Weight | 380.00 Kg |
