CEE plug 32A, 5-pin, 400V with top cable entry (12–22 mm). Fitted with screw terminals and quick-lock system (turn2fix). Splash-proof according to IP44 and compliant with VDE 0623, EN 60309 and IEC 60309. Equipped with unplated contacts and a 6h position indicator.
Specifications
| Rated current (400V) | 32A |
| Voltage | 400V |
| Poles number | 5 |
| Cable entry | Screw swivel |
| IP grade | IP44 |
| Material | Thermoplastic |
| Connection type | Screw clamp |
| Angle of plug | Straight |
| Earth pin position | 6h (IEC 60309) |
| Cable diameter | 8 - 16 mm |
| Voltage according to EN 60309-2 | 400V (50+60 Hz) |
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
| Product Dimensions: | |
|---|---|
| Product Length | 285 mm |
| Product Width | 185 mm |
| Product Height | 130 mm |
| Product Weight | 0.163 Kg |
| Package Dimensions: | |
| Package Length | 0 mm |
| Package Width | 0 mm |
| Package Height | 0 mm |
| Package Weight | 0.00 Kg |
| Package Type: | |
| Overdoos | 5 Pcs |
