Tire balancer / wheel balancer
The Fasep "Compact" balancing machine is equipped with all the important functions needed to balance tires accurately, easily and quickly. The machine has the following features:
19" LCD screen with separate control panel.
ALU-SE: Automatic measuring arm including adapter for placing stick-on weights.
TriSensor: 3-sensor system to measure the imbalance.
IFS: Integrated-flange shaft for maximum centering accuracy.
3D size entry for automatic entry of the rim width.
Laser line: System for the precise application of stick-on weights in the rim. The laser line clearly shows where the weight should be applied.
Electromagnetic brake to lock the wheel.
Safety cover with space-saving design.
Storage space for weights, cones and tools.
This automated balancing machine is suitable for wheels on cars, vans, SUV`s and small trucks.
voltage = 230V / 50Hz
power = 400W
motor power = 50W
speed = 98rpm
rim diameter = 10" (254mm) - 26" (650mm)
max. wheel diameter = 34" (850mm)
max. rim width = 16" (415mm)
max. capacity = 75kg
cycle duration = 8 - 15 sec.
measurement accuracy = 1 gram
angle accuracy = 256 divisions
noise level = <70dB
Each V548 comes standard with: balancing clamp 40mm, cone set, rim width meter, wheel pliers, spanner and 4 ground anchors.
