Welding chuck

This welding chuck 3-jaw is ideal for the use on a welding positioner. This secures the workpiece to the welding manipulator so that an excellent welding connection is realized.
Especially suitable for series production. Many of the same work pieces can easily be changed, resulting in a shorter production time.

• diameter = 400mm

• reach round = 120 -380mm

• clamping force = 350kg

• capacity = 240g

• reach outside jaws = 250 - 380mm

• reach inside jaws = 120 - 250mm



Suitable for the welding positioner 300kg (LM30)

Welding chuck

This welding chuck 3-jaw is ideal for the use on a welding positioner. This secures the workpiece to the welding manipulator so that an excellent welding connection is realized.

Especially suitable for series production. Many of the same work pieces can easily be changed, resulting in a shorter production time.

- diameter = 300mm

- reach round = 80 -280mm

- clamping force = 250kg

- capacity = 120g

- reach outside jaws = 170 - 280mm

- reach inside jaws = 80 - 190mm

Suitable for the welding positioner 100kg (LM10)
