The Hugong Extreme120 is a powerful, compact, and lightweight electrode welding machine, developed for mobile use. Its handy design and easily adjustable welding current make it especially suitable for on-site work and welding tasks involving various material thicknesses.
Modern IGBT inverter technology ensures a stable arc, high efficiency, and reliable performance. An integrated cooling fan and thermal protection system guard the machine against overheating, even during intensive use. The hot-start and anti-stick functions simplify arc ignition and help prevent the electrode from sticking to the workpiece.
The Extreme120 is suitable for welding carbon steel, low-alloy steel, and stainless steel, and works perfectly with both rutile (E6013) and basic (E7018) electrodes in the 1.6 to 3.2 mm range.
- Stepless current adjustment
The welding current can be adjusted smoothly and precisely via a rotary knob. This ensures accurate matching to material, electrode, and desired weld depth.
- Mobile
Thanks to inverter technology, the device is lightweight and compact. Combined with the shoulder strap, it is easy to carry.
- Digital display
The screen clearly shows the set welding current.
- ABS shock-resistant housing
The ABS housing provides protection against impacts, dust, and light moisture.
- 5-year warranty
Long-term security thanks to extended factory warranty after online registration.
Supplied with:
- Electrode holder with 3-meter welding cable
- Ground clamp with 2-meter cable (13 mm²)
- Neoprene power cable
- Shoulder strap
Specifications
| Voltage | 230V - 1 Phase |
| Rated input current | 23A |
| Frequency | 50/60 Hz |
| Input power | 5.06kVA |
| Circuit breaker | 16A B-char |
| No load voltage | 65V |
| Welding current range | 20 - 120A |
| Duty cycle @20C | 30% - 120A |
| Duty cycle @40C | 15% - 200A |
| Welding electrodes | 1.6 - 2.5m |
| Protection class | IP21S |
| Product Dimensions: | |
|---|---|
| Product Length | 315 mm |
| Product Width | 102 mm |
| Product Height | 176 mm |
| Product Weight | 2.65 Kg |
| Package Dimensions: | |
| Package Length | 325 mm |
| Package Width | 225 mm |
| Package Height | 230 mm |
| Package Weight | 3.00 Kg |
