Hydraulikzylinder
It has the characteristic of a low collapsed height. If the requirement of stroke needs to be higher, the ZFL cylinders are recommended.
The surface of principle axis is finished with chrome plate.
Plunger has the function of retracting automatically.
- output = 200 ton
- stroke = 50mm
- effective area = 22cm^2
- oil capacity = 0,14 L
- height of product = 98mm
- extended height = 148mm
- outside diameter = 88mm
- bore diameter = 65mm
- plunger diameter = 53mm
- thread for input oil port (ZG) = 3/8" - 19
- saddle protrusion form plgr = 2mm
- saddle is removable
- max. pressure = 700bar
Produkt Abmessungen:
| Length | 160 mm |
|---|---|
| Width | 90 mm |
| Height | 100 mm |
| Weight | 4,0 kg |
Abmessungen der Verpackung:
| Length | 240 mm |
|---|---|
| Width | 275 mm |
| Height | 225 mm |
| Weight | 5,00 kg |
